Recursive types, finite values: an EIP-712 bug in alloy

EIP-712 says, in so many words, that it supports recursive struct types. alloy — the Ethereum Rust library under Foundry and Reth — refused to canonicalize one. Neither side was being careless: the spec is explicit, and a library that rejects cyclic types is doing exactly what it should. The bug lived in the inch between those two facts.

EIP-712 is the standard behind almost every “sign this” prompt your wallet shows you: it takes a structured message, hashes it deterministically, and lets a contract verify the signature on-chain. The deterministic part hinges on canonicalization — turning a type like Mail(address from,address to,string contents) into exactly one agreed-upon string, so the signer and the verifier hash the same bytes. (What makes it canonical: when a struct references other structs, those referenced types are collected, sorted by name, and appended — exactly one legal ordering, so exactly one string per type.) Here’s a type that is perfectly legal under EIP-712, and that alloy rejected anyway:

#[test]
fn canonicalize_self_referential_type() {
    // Per EIP-712: "The standard supports recursive struct types."
    let input = "Node(uint256 value,Node[] children)";
    let encoded = EncodeType::parse(input).unwrap();
    assert_eq!(encoded.canonicalize(), Ok(input.to_string()));
}

A Node has a value and some child Nodes — a tree. On main, that test failed:

left:  Err(MissingType("primary component"))
right: Ok("Node(uint256 value,Node[] children)")

The parser accepted the string without complaint. The rejection happened later, in canonicalize.

The distinction the spec makes and the code didn’t

The EIP-712 spec says, plainly:

The standard supports recursive struct types.

And then, in the rationale:

The current standard is optimized for tree-like data structures and undefined for cyclical data structures.

Read those together and the whole bug falls out. A recursive type definition is allowed — it describes a possibly-self-referencing shape. A cyclical data instance — a runtime value that loops back on itself — is undefined; every concrete value still has to be a finite tree. Node the type can mention Node. A particular Node value cannot contain itself; it just contains some children, which eventually bottom out.

Canonicalization operates on the type definition. So it has to accept self-reference. The code conflated the two: anything that pointed at itself was treated as a cycle, and cycles were rejected wholesale. To find the “primary” type to canonicalize, the resolver leaned on its cycle/dependency machinery — and a self-referential type registers as depending on itself, so the lookup came back empty and bailed with MissingType("primary component") before it ever produced a string.

The bug lived in the seam between two correct rules — “reject cyclic types” and “the spec allows recursion.” The fix splits one cycle check into a permissive (type-level) and a strict (value-level) pass.

The fix: two cycle checks, not one

The resolver already had one cycle detector. The fix splits it in two, keyed on what the caller is going to build:

Resolver::resolve materializes a concrete DynSolType — an actual value shape. That genuinely cannot represent recursion (you can’t build an infinitely-nested value), so it keeps the strict check and still rejects any self-reference.
Resolver::linearize / encode_type only produce the encodeType string. That’s pure type-level work, so it gets a permissive check that allows a type to reference itself.

Concretely, detect_cycle_inner gained an allow_self_refs flag, and the permissive path skips the self-edge instead of treating it as a cycle:

// EIP-712 permits recursive struct types, so a self-edge is
// not treated as a cycle when `allow_self_refs` is enabled.
if allow_self_refs && edge == type_name {
    continue;
}

Crucially, it only forgives a type pointing at itself. A cycle between two distinct types — A depends on B depends on A — is still a CircularDependency error, because that isn’t a recursive struct, it’s a malformed type graph.

The second half lived in the parser. canonicalize had been eagerly calling resolver.resolve(primary)? as a validation step before encoding — which is exactly the path that can’t represent recursion. Dropping that pre-check and going straight to encode_type (which now walks the permissive linearize) lets the recursive type through while still surfacing genuine missing-type and circular-dependency errors:

// We intentionally do not call `Resolver::resolve` here, because that
// builds a `DynSolType` and therefore cannot represent recursive struct
// types (which EIP-712 explicitly permits).
resolver.encode_type(primary)

A second regression test covers the case that also has a real dependency — Tree(Leaf root,Tree[] subtrees)Leaf(uint256 value) — to make sure the recursive primary type still pulls in Leaf and orders it correctly.

Why I care about a missing primary component

This is a small diff. But it’s the kind of bug I go looking for. Two rules, each correct alone — “reject cyclic types” and “the spec allows recursion” — and no test ever stood in the gap where they disagree. That gap is where signature and verification bugs almost always live: not in either rule, but in the join nobody wrote down.

And EIP-712 canonicalization isn’t a backwater. It’s on the path of every typed-data signature that flows through the Rust Ethereum stack — every Foundry script that signs a permit, every tool built on alloy that verifies one. A type the spec says is valid should not be un-signable because of how the library happened to find its primary component.

Fixed in alloy-rs/core#1105, closing #1103.
